The electric actuator PROFOX offers a 90° +/- 15° rotation range, 80-600 Nm torque, IP 67 protection, and an aluminium housing with anti-corrosion protection. Duty cycles are S2: 15 minutes and S4: 50%, with up to 1200 starts per hour.
Flanged ball valve with floating ball, full bore Body in steel 1.0619 WCB Ball in stainless steel CF8 Seats in PTFE Max. working pressure: 20 bar Face to face: ASME B16.10 long pattern Connection: flanged ANSI 150 Lbs ISO mounting flange Fire safe according to ISO 10497 With manual fail-safe spring unit
| Specification | Value |
|---|---|
| Square, star (mm) | 14 |
| Manual override | By handwheel |
| Torque (Nm) | 80 |
| Declutchable | Yes |
| Starts/h (engine) | 1200 |
| Duty service | Duty service S2 - 15 min / S4 - 50%. |
| 3D indicator | Yes |
| Protection index (IP) | IP 67 |
| Torque limiter | Yes |
| Recommended location | Outdoor |
| Body material | Aluminium |
| ISO pad 5211 | F5/F7/F10 |
| Power (W) | 52 |
| Function | On-off |
| Electric actuator type | PF-Q |
| Electric actuator series | Profox series (AUMA) |
| Voltage | 230 V AC |
| TS max (°C) | 70 |
| TS min (°C) | -30 |
| Warranty period | 1 year |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| Aluminium 230 V AC 80 | 027110 | S1006022 |
€2,852.11
(excl. btw)
|
add to cart |
| Aluminium 24 V DC 80 | 027114 | S1006023 |
€2,709.63
(excl. btw)
|
add to cart |
| Aluminium 230 V AC 150 | 027120 | S1006024 |
€3,109.06
(excl. btw)
|
add to cart |
| Aluminium 24 V DC 150 | 027124 | S1006025 |
€2,954.23
(excl. btw)
|
add to cart |
| Aluminium 230 V AC 300 | 027130 | S1006026 |
€3,123.66
(excl. btw)
|
add to cart |
| Aluminium 24 V DC 300 | 027134 | S1006027 |
€3,123.66
(excl. btw)
|
add to cart |
| Aluminium 230 V AC 600 | 27140 | S1006028 |
€0.00
(excl. btw)
|
add to cart |
| Aluminium 24 V DC 600 | 27144 | S1006029 |
€0.00
(excl. btw)
|
add to cart |
