Ball Valve DN15 PN16 DIN FLANGED C.S. 1.0619 Z04 TTTG PN16
1.00€
| Specification | Value |
|---|---|
| Artikel nr | P100000 |
| Sub-1 | Valves |
| Sub-2 | Ball Valves |
| Combi ID | Z04 TTTG PN16 |
| Size | DN15 |
| Pressure Class | PN16 |
| Category | BVM |
| Price | 97.35 |
| Standard(ANSI/DIN/JIS) | DIN |
| Connection: | FLANGED |
| Body Type | F2 |
| Operator | Lever |
| Bore: | FB |
| Body material | C.S. 1.0619 |
| Ball Material | S.S. 1.4408 |
| Stem Material | S.S. 1.4401 |
| Seat material | PTFE (modified) |
| Construction1 | Floating |
| Construction2 | Two Piece Body |
| Amount of Connections: | Two Way |
| 3.1 Certification | Yes |
| Locking Device | Optional |
| 3.1 Certificate | PEKOS |
| Model Nr. | F.Z04 |
| Torque | 12 |
| MAST | 44 |
| Stemsize | 11 |
| Stemheight | 11 |
| F-Connection1 | F05 |
| Direct Mounting | NO |
| weight (KG) | 3 |
